# Analytical Design

Using symbolic dynamics to design fractal artwork.

# 1 Beyond 23

Starting from the embedded Julia set with angled internal address 1 2 3 1/8 23.

Morph to the period 49 = 2 * 23 + 3 node in the 1/2 wake.

Morph to the period 101 = 2 * 49 + 3 node in the 1/2 wake.

Repeat this process indefinitely.

# 1.1 Angled Internal Address

A small Haskell program to calculate the angled internal address of the nth item in the sequence, starting from period = 23 at n = 1:

import Data.List (intercalate)

address n
  = ("1 2 3 1/8 " ++)
  . intercalate " "
  . map show
  . take n
  . iterate (\p -> 2 * p + 3)
  $ 23

# 1.2 External Angle

These strings can be parsed and converted to pairs of external angles, which are conveniently expressed as periodic binary expansions:

import Mandelbrot.Prelude

angles
  = both (drop 2 . init . plain . binary)
  . addressAngles
  . pAddress
  . address -- defined above

both f (a, b) = (f a, f b)

Converting angled internal addresses to binary angles takes some time. Concatenating strings is much quicker. The next step is figuring out which strings to concatenate.

# 1.3 Pattern Analysis

Output the first few sets of angles:

import Control.Monad (forM_)

main = forM_ [1..5] $ \n -> do
  let (lo, hi) = angles n
  putStrLn (show n)
  putStrLn ""
  putStrLn lo
  putStrLn ""
  putStrLn hi
  putStrLn ""

Which outputs

1

01101101101101101101110

01101101101101101110001

2

0110110110110110110111001101101101101101110001100

0110110110110110111000101101101101101101101110011

3

01101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001011100

01101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001100011

4

0110110110110110111000101101101101101101101110011011011011011011011011100110110110110110111000110001101101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001011011100

0110110110110110111000101101101101101101101110011011011011011011011011100110110110110110111000110001101101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001011100011

5

01101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001100011011011011011011011100010110110110110110110111001101101101101101101101110011011011011011011100010111000110110110110110110111000101101101101101101101110011011011011011011011011100110110110110110111000110001101101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001011011011100

01101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001100011011011011011011011100010110110110110110110111001101101101101101101101110011011011011011011100010111000110110110110110110111000101101101101101101101110011011011011011011011011100110110110110110111000110001101101101101101101110001011011011011011011011100110110110110110110110111001101101101101101110001011011100011

This is pretty opaque, but using the knowledge that (typically) later bitstrings are made by copy-pasting earlier bitstrings, and guided by the \p -> 2 * p + 3 pattern of the periods, try to reformat it so any patterns are visible:

1

01101101101101101101110

01101101101101101110001

2

01101101101101101101110
01101101101101101110001 100

01101101101101101110001
01101101101101101101110 011

3

01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 100

01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011

4

01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 011 100

01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 100 011

5

01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 011 011 100

01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 100 011
01101101101101101110001
01101101101101101101110 011
01101101101101101101110
01101101101101101110001 011 011 100 011

Labelling the lower angle at each stage o, and the upper i, the first step from 1 to 2 is:

\(o, i) -> (o ++ i ++ "100", i ++ o ++ "011")

The second step from 2 to 3 is already trickier, but at least the upper part is the same:

\(o, i) -> (i ++ ?, i ++ o ++ "011")

The third step from 3 to 4 is confusing so far. Looking at the step from 4 to 5, the pattern seems to be revealed: it’s almost like

\(o, i) -> (i ++ o, i ++ i)

but each new block has “011” inserted 6 digits from the end.

# 1.4 Conjecture

The above leads to the following conjecture:

pattern (o, i) =
  ( i ++ replaceSuffix "011100" "011011100" o
  , i ++ replaceSuffix "100011" "011100011" i
  )

replaceSuffix needle replacement haystack
  | needle == haystack = replacement
  | otherwise = case haystack of
      h:hs -> h : replaceSuffix needle replacement hs
      [] -> error "replaceSuffix: not found"

where checking for the expected suffix is to help to detect if the conjecture is valid.

The expected suffix only exists from stage 3, so that’s the seed.

# 1.5 Theorem

Testing the conjecture:

main = forM_ [3 .. 7] $ \n -> do
  print $ iterate pattern (angles 3) !! (n - 3) == angles n

prints True for these test cases so I suppose its ok (not proven rigourously though!). It takes over a minute to run in Hugs, the time being dominated by address to angle calculations.

# 1.6 Extrapolation

The list of periods ending at the first over 1M can be printed by:

main
  = putStrLn
  . unwords
  . map show
  . take 17
  . iterate (\p -> 2 * p + 3)
  $ 23

which outputs

23 49 101 205 413 829 1661 3325 6653 13309 26621 53245 106493 212989 425981 851965 1703933

And one of the final angles can be printed by:

main
  = putStrLn
  . (".(" ++) . (++ ")")
  . fst
  . (!! 14)
  . iterate pattern
  . angles
  $ 3

which outputs a 1.7MB string that I won’t include here, taking about 5 seconds in Hugs (much faster than converting address to angles).

# 1.7 Ray Tracing

The whole point of this stuff with external angles, is that they can be converted to coordinates for rendering images, using an algorithm called “external ray tracing”.

The program m-exray-in-via (part of my mandelbrot-numerics library) traces external rays using perturbation techniques, given an angle (on stdin) and a list of periods (as arguments) of references to use.

The period and coordinates of the references are output (along with two more numbers which are for internal debugging). Here I piped though ts, which shows that each next reference takes over twice as long. As the 11th step took 23mins, the 17th step is expected to finish in a few days.

Jul 17 09:03:35 23 -1.74633514734717192999519e+00 2.07795428756447413325244e-03 0.0000000000000000e+00 0.0000000000000000
Jul 17 09:03:35 49 -1.74633486482589918992643768e+00 2.07684336209284403849083121e-03 1.7463363836197453e+00 179.9318241090836587
Jul 17 09:03:35 101 -1.746336323507542951806601830636364626e+00 2.077698750144148599452026855476806781e-03 1.1462869069596916e-06 -75.7314866467596709
Jul 17 09:03:36 205 -1.74633633100972859200274231936097238667210e+00 2.07770993199709122129778689580850218177491e-03 1.6909881301069132e-06 149.6121394759637552
Jul 17 09:03:38 413 -1.74633633100731203448693541857192011832282528195609e+00 2.07770992931759947498951156281311613332803673420334e-03 1.3465386166404066e-08 123.8586514515695381
Jul 17 09:03:45 829 -1.746336331007312034486935402967007740930139175151113471916062817428e+00 2.077709929317599474989506042011876088075158436781760255391826095601e-03 3.6082442053908975e-12 -47.9535967875120835
Jul 17 09:04:15 1661 -1.7463363310073120344869354029670077409231543658125461180309896474285249339529727807454356605e+00 2.0777099293175994749895060420118760848491869012422276656716077111313848709361939567416133797e-03 1.6552719916623632e-26 -19.4830720472748943
Jul 17 09:05:52 3325 -1.74633633100731203448693540296700774092315436581254611803325193168381308728011150208513167019595429158355305443112947196533853088e+00 2.07770992931759947498950604201187608484918690124222766722007389279534979028185356123800225021156175232502789685337340415867851975e-03 7.6937932025918790e-39 -24.7901065222730735
Jul 17 09:10:06 6653 -1.746336331007312034486935402967007740923154365812546118033251931683813087280111502085627299341858766423513060798655737625169488900814755877361940049002481303016793848494744162753267047e+00 2.077709929317599474989506042011876084849186901242227667220073892795349790281853560896466147113669128422879380314191609810670105698882015552396775664490620081686570655143335730199976986e-03 2.7414736123992976e-57 145.6095220480795800
Jul 17 09:20:03 13309 -1.74633633100731203448693540296700774092315436581254611803325193168381308728011150208562729934185876642351306079865573762516948551841422971135489737098688353733425703865667227138991254140559019793350691207072113819940540511458099026453359117235390439801001721027451330201e+00 2.07770992931759947498950604201187608484918690124222766722007389279534979028185356089646614711366912842287938031419160981067058106210846403016855798078929551431193963843476051125938777415015216658903876498407877900737863618682598393346026300747387440414714831108853043638e-03 6.0190959453168176e-85 -145.4294253976338218
Jul 17 09:43:16 26621 -1.7463363310073120344869354029670077409231543658125461180332519316838130872801115020856272993418587664235130607986557376251694855184142297113548973709868835373342570386566722713899125414055900856695267201713924036710692220103507637521944471562516911831707895410112192365516663041743684904516658982814000368156021939494396953072509759875690029947902239064728734155917392297586463904695791943165224848e+00 2.0777099293175994749895060420118760848491869012422276672200738927953497902818535608964661471136691284228793803141916098106705810621084640301685579807892955143119396384347605112593877741501153889029566315408379148394711413737563464890849555801807507921137751989616893605705660059914141883303008691430816086889542375429088277134971473479217183850413207936618885384522404550042749231947447586323457373e-03 3.4156410110647738e-126 7.9999640067258766

Unfortunately external ray tracing is an inherently serial algorithm, so multicore CPU or GPU are no benefit.

# 1.8 Viewport

The coordinates are only the center of the view. To render an image, the size (zoom depth) is also needed.

From prior experience, the zoom depth of an embedded Julia morph is often related to the atom domain size by an exponent of 9/8 and a constant scale factor (typically in the range 1 to 100).

For example, the period 3325 nucleus in the output above, fed into m-domain-size from mandelbrot-numerics, arbitrarily using 1000 bits of precision (too low will cause errors, too high will waste computation time), gives

1.0081875719169438e-75

Using Hugs as a calculator, noting that zoom = 4 / size (some software uses size, some uses zoom):

> 4 / (10 * 1.0081875719169438e-75 ** 1.125)
9.39887739382545e+83

# 1.9 Image

Feeding the coordinates and zoom depth to Fraktaler-3 gives this image of the period 3325 stage:

Beyond 23 image

Parameters: F3 TOML

The period 1.7M image (when the ray tracing finishes…) will be added to my Millionaires page.

# 2 Right 23

Doing the same as Beyond 23, but with ìntercalate " 1/3 " instead of intercalate " " gives a simpler pattern:

1

01101101101101101101110

01101101101101101110001

2

01101101101101101101110
01101101101101101101110 100

01101101101101101101110
01101101101101101110001 011

3

01101101101101101101110
01101101101101101101110 100
01101101101101101101110
01101101101101101101110 100 100

01101101101101101101110
01101101101101101101110 100
01101101101101101101110
01101101101101101110001 011 011

4

01101101101101101101110
01101101101101101101110 100
01101101101101101101110
01101101101101101101110 100 100
01101101101101101101110
01101101101101101101110 100
01101101101101101101110
01101101101101101101110 100 100 100

01101101101101101101110
01101101101101101101110 100
01101101101101101101110
01101101101101101101110 100 100
01101101101101101101110
01101101101101101101110 100
01101101101101101101110
01101101101101101110001 011 011 011

That is:

pattern (o, i) =
  ( o ++ o ++ "100"
  , o ++ i ++ "011"
  )

Tracing rays gives:

Jul 17 12:02:50 23 -1.74633514734717192999519e+00 2.07795428756447413325244e-03 0.0000000000000000e+00 0.0000000000000000
Jul 17 12:02:50 49 -1.74633548145057916309793739e+00 2.07914200586261670841929230e-03 1.7463363836197453e+00 179.9318241090836587
Jul 17 12:02:50 101 -1.74633547654049046285826942621248e+00 2.07914062238913243500916524343038e-03 1.2338151573341379e-06 105.7112143536725770
Jul 17 12:02:51 205 -1.746335476541127790415919525459487428586e+00 2.079140623084958192471124461783761576532e-03 5.1012714028866257e-09 -15.7357876035526123
Jul 17 12:02:53 413 -1.74633547654112779262053742329718025298547262977044e+00 2.07914062308495897791130824388486742822322555623627e-03 9.4358884080289435e-13 132.4874973028281012
Jul 17 12:03:00 829 -1.7463354765411277926205374142161053858041595736529061182109921309366e+00 2.0791406230849589779113109568610982917092689841778834669666415868234e-03 2.3403538958383940e-18 160.3905196109885694
Jul 17 12:03:30 1661 -1.74633547654112779262053741421610538580179078976421433044236742556582718071020357279312111983e+00 2.07914062308495897791131095686109829080307837412287377319236163733274019073942514209017327317e-03 9.4776664201997714e-27 16.6335451044815726
Jul 17 12:05:07 3325 -1.7463354765411277926205374142161053858017907897642143304422898565104236627345880158560056740211239262554101509467874550219165330426e+00 2.0791406230849589779113109568610982908030783741228737728402854243538020678750404853300909892074335568290309982799825737920118083704e-03 2.5362015955120088e-39 -20.9346118819963777
Jul 17 12:09:15 6653 -1.746335476541127792620537414216105385801790789764214330442289856510423662734588015855987027871163667573832967002426725605666001851805343180940944269010997417634380981513578297317034415088e+00 2.079140623084958977911310956861098290803078374122873772840285424353802067875040485336082803222190035928481963222673695603777482276706940346699339043684873091097262891413391475227844213305e-03 3.6051992746835041e-58 -77.5751527593522321
Jul 17 12:18:53 13309 -1.7463354765411277926205374142161053858017907897642143304422898565104236627345880158559870278711636675738329670024267256056660018443489946553313404559202268490628017620503563634095506937110192797415604053048668480558653492508830444787389840891221817510279997087232310591165e+00 2.0791406230849589779113109568610982908030783741228737728402854243538020678750404853360828032221900359284819632226736956037774797544371833280730260354639334453740478446865805441311732487975533775486416164613046386955993459028886847904321339326352283211443061129550601091279e-03 1.9585217474613015e-86 17.8144568675296505
Jul 17 12:41:31 26621 -1.74633547654112779262053741421610538580179078976421433044228985651042366273458801585598702787116366757383296700242672560566600184434899465533134045592022684906280176205035636340955069371101928032055610539385971916785767049203379135087882280443738417754349637444493386226357981870029963204858519974407442209622983671782848395008727873317324880873373328310837905044901729078734254174186460862945983584e+00 2.07914062308495897791131095686109829080307837412287377284028542435380206787504048533608280322219003592848196322267369560377747975443718332807302603546393344537404784468658054413117324879755529578348024287636934712042391518848197455735625663389463343081078768622277891312183241452328711204654041476011886582755781572600252658299028251613679662119426375645281472290072066004394302991612379467701189962e-03 7.8714025473565586e-129 -18.6892099130054960

The period 3325 image is then:

Right 23 image

Parameters: F3 TOML

The atom domain size linear scale factor is 12 instead of 10.

# 3 Left 23

Doing the same as Beyond 23, but with ìntercalate " 2/3 " instead of intercalate " " gives another simple pattern:

pattern (o, i) =
  ( i ++ o ++ "100"
  , i ++ i ++ "011"
  )

However, trying to trace the rays failed quite early:

Jul 17 12:35:39 23 -1.74633514734717192999519e+00 2.07795428756447413325244e-03 0.0000000000000000e+00 0.0000000000000000
Jul 17 12:35:39 49 -1.74633402413115550228934451e+00 2.07826598696372738135560175e-03 1.7463363836197453e+00 179.9318241090836587
Jul 17 12:35:40 101 -1.7463348724496896286564354786783866e+00 2.0768655013555391353975085414886591e-03 1.1656632168231784e-06 15.5096639188026663
Jul 17 12:35:40 205 -1.74633486339842676418514603941107177368347498e+00 2.07684837296023536872562393360703779267932562e-03 1.6373772546620737e-06 -121.2046184400369639
m-exray-in-via: error: nucleus failed at period = 413 (depth = 1735)

I worked around it by adding 8 to the target dwell (equivalent to adding 24 to depth), which is when to stop tracing the ray and switch to Newton’s root finding method to locate the nucleus.

Not entirely satisfied, but it let me get this period 3325 image:

Left 23 image

Parameters: F3 TOML

The atom domain size linear scale factor is 12 instead of 10.

I struggle to see the difference to the Right image, perhaps I will try orienting them the same, by using the next nucleus in the series as a “handle”. Perhaps the differences are only visible in the rings of decorations, and not the central feature, so zooming out a little is another idea to try.

# 4 Before 23

Doing the same as Beyond 23, but going to the node opposite the 1/2 wake, needs some care as the angled internal addresses are no longer so simple.

  1. use a graphical explorer to find the nodes

  2. trace their rays outwards to find their external angles

  3. reverse engineer the pattern of external angles

The pattern turned out to be another simple one:

pattern (o, i) =
  ( o ++ o ++ "011"
  , i ++ i ++ "100"
  )

starting from the period 23 island.

Period 3325 image:

Before 23 image

Parameters: F3 TOML

The atom domain size linear scale factor is 12 instead of 10.

The angled internal addresses corresponding to the nodes are:

1 2 3 1/8 23

1 2 3 1/8 24  25 26  47 48  49

1 2 3 1/8 24  25 26  47 48  50  51 52  73 74 75  96 97  99 100  101

1 2 3 1/8 24  25 26  47 48  50  51 52  73 74 75  96 97  99 100  102
103 104  125 126 127  148 149  151 152 153  174 175 176  197 198  200 201  203 204  205

1 2 3 1/8 24  25 26  47 48  50  51 52  73 74 75  96 97  99 100  102
103 104  125 126 127  148 149  151 152 153  174 175 176  197 198  200 201  203 204  206
207 208  229 230 231  252 253  255 256 257  278 279 280  301 302  304 305  307 308 309
330 331 332  353 354  356 357 358  379 380 381  402 403  405 406  408 409  411 412  413

What a mess! No hope of reverse engineering that.

# 5 Inside 23

Exploring graphically in m-perturbator-gtk (in the same 1 2 3 1/8 23 embedded Julia set) and tracing some rays gave the following pattern of external angles:

import System.IO (hPutStrLn, stderr)

periods = iterate (\p -> 2 * p + 23 + 1) (23 + 23 + 1)

o23 = "01101101101101101101110"
i23 = "01101101101101101110001"

seed =
  ( o23 ++ i23 ++ "1"
  , i23 ++ o23 ++ "0"
  )

pattern (o, i) =
  ( o ++ i ++ i23 ++ "1"
  , i ++ o ++ o23 ++ "0"
  )

main = do
  hPutStrLn stderr . unwords . map show . take 10 $ periods
  putStrLn $ ".(" ++ (fst $ iterate pattern seed !! 10) ++ ")"

The period 4520 image looks like:

Inside 23 image

Parameters: F3 TOML

Exploration: MP TOML

# 5.1 Elephant Balls

As above, but with denominator in 1/8 varied from 2 to 17:

Elephant Balls image

Haskell program to generate variations of a given depth d and denominator n, file eb.hs:

import Mandelbrot.Prelude (plain, binary, addressAngles, pAddress)
import System.Environment (getArgs)

import System.IO (hPutStrLn, stderr)

periods n = m : iterate (\p -> 2 * p + m + 1) (2 * m + 1)
  where
    m = 3 * n - 1

angles n
  = both (init . drop 2 . plain . binary)
  . addressAngles
  . pAddress
  $ "1 2 3 1/" ++ show n ++ " " ++ show (3 * n - 1)

both f (a, b) = (f a, f b)

seed (o, i) =
  ( o ++ i ++ "1"
  , i ++ o ++ "0"
  )

pattern (oo, ii) (o, i) =
  ( o ++ i ++ ii ++ "1"
  , i ++ o ++ oo ++ "0"
  )

main = do
  [sd, sn, mode] <- getArgs
  d <- readIO sd
  n <- readIO sn
  case mode of
    "p" -> putStrLn . unwords . map show . take d . periods $ n
    "a" -> let oi = angles n
           in  putStrLn $ ".(" ++ fst (iterate (pattern oi) (seed oi)  !! (d - 2)) ++ ")"

Script to render animation (file eb.sh):

#!/bin/bash
for p in $(seq 2 17)
do
  mandelbrot-prelude/runhugs.sh eb.hs 7 $p a |
  m-exray-in-via $(mandelbrot-prelude/runhugs.sh eb.hs 7 $p p) |
  tee eb-$p.txt
  cat eb-$p.txt |
  tail -n 2 |
  (
    read q cre cim junk
    read q dre dim junk
    ghc -e "let x = fromRational (($dre) - ($cre)) ; y = fromRational (($dim) - ($cim)) in putStrLn (\"location.real = \\\"$cre\\\"\\nlocation.imag = \\\"$cim\\\"\\nlocation.zoom = \\\"\" ++ show (0.02 * 4 / sqrt (x^2 + y^2)) ++ \"\\\"\\ntransform.rotate = \" ++ show (360 / (2 * pi) * atan2 y x) ++ \"\\nrender.filename = \\\"eb-$p\\\"\")"
  ) |
  tee eb-$p.f3.toml
  fraktaler-3-3~pre -P -b eb.f3.toml eb-$p.f3.toml
done
ffmpeg -r 3 -i eb-%d.png -y eb.gif

Common F3 TOML for rendering setup (file eb.f3.toml):

bailout.iterations = 100100
bailout.maximum_reference_iterations = 100100
bailout.maximum_perturb_iterations = 4096
bailout.maximum_bla_steps = 4096
image.width = 640
image.height = 640
image.subframes = 16
render.save_png = true

[colour]
uniforms = []
shader = """
vec3 colour(void)
{
  const float gamma = 1.0;
  vec2 DE = getDE();
  float val = tanh(clamp(length(DE), 0.0, 4.0));
  return vec3(pow(val, 1.0 / gamma));
}
\
"""

# 6 Inside 23 3/8

Replacing 1/8 with 3/8 in the initial seed gives a variation:

Inside 23 3/8 image

Parameters: F3 TOML

# 7 Line 23

Exploring extending a line in the 1/2 wake, this pattern works by splitting the digit blocks in half and swapping them over.

import System.IO (hPutStrLn, stderr)

o23 = "01101101101101101101110"
i23 = "01101101101101101110001"

seed =
  ( o23 ++ i23 ++ "10" ++ i23 ++ i23 ++ "10"
  , i23 ++ o23 ++ "01" ++ o23 ++ o23 ++ "01"
  )

pattern (o, i) =
  ( o ++ i1 ++ o2
  , i ++ o1 ++ i2
  )
  where
    (o1, o2) = split o
    (i1, i2) = split i

split xs = half xs xs
  where
     half (x:xs) (_:_:ys) = first (x:) (half xs ys)
     half xs [] = ([], xs)
     half _ _ = error "split: length is odd"
     first f ~(xs, ys) = (f xs, ys)

periods = 23 : iterate (* 2) 48

main = do
  hPutStrLn stderr . unwords . map show . take 17 $ periods
  putStrLn $ ".(" ++ fst (iterate pattern seed !! 14) ++ ")"

Line 23 3/8 image

Parameters: F3 TOML

Exploration: MP TOML

# 7.1 Elephant Lines

As above, but with denominator in 1/8 varied from 2 to 17:

Elephant Lines image

Haskell program to generate variations of a given depth d and denominator n, file el.hs:

import Mandelbrot.Prelude (plain, binary, addressAngles, pAddress)
import System.Environment (getArgs)

periods n = (3 * n - 1) : iterate (* 2) ((3 * n - 1) * 2 + 2)

angles n
  = both (init . drop 2 . plain . binary)
  . addressAngles
  . pAddress
  $ "1 2 3 1/" ++ show n ++ " " ++ show (3 * n - 1)

both f (a, b) = (f a, f b)

seed (o, i) =
  ( o ++ i ++ "10" ++ i ++ i ++ "10"
  , i ++ o ++ "01" ++ o ++ o ++ "01"
  )

pattern (o, i) =
  ( o ++ i1 ++ o2
  , i ++ o1 ++ i2
  )
  where
    (o1, o2) = split o
    (i1, i2) = split i

split xs = half xs xs
  where
     half (x:xs) (_:_:ys) = first (x:) (half xs ys)
     half xs [] = ([], xs)
     half _ _ = error "split: length is odd"
     first f ~(xs, ys) = (f xs, ys)

main = do
  [sd, sn, mode] <- getArgs
  d <- readIO sd
  n <- readIO sn
  case mode of
    "p" -> putStrLn . unwords . map show . take d . periods $ n
    "a" -> putStrLn $ ".(" ++ fst (iterate pattern (seed (angles n)) !! (d - 3)) ++ ")"

Script to render animation (file el.sh):

#!/bin/bash
for p in $(seq 2 17)
do
  mandelbrot-prelude/runhugs.sh el.hs 8 $p a |
  m-exray-in-via $(mandelbrot-prelude/runhugs.sh el.hs 8 $p p) |
  tee el-$p.txt
  cat el-$p.txt |
  tail -n 2 |
  (
    read q cre cim junk
    read q dre dim junk
    ghc -e "let x = fromRational (($dre) - ($cre)) ; y = fromRational (($dim) - ($cim)) in putStrLn (\"location.real = \\\"$cre\\\"\\nlocation.imag = \\\"$cim\\\"\\nlocation.zoom = \\\"\" ++ show (0.5 * 4 / sqrt (x^2 + y^2)) ++ \"\\\"\\ntransform.rotate = \" ++ show (360 / (2 * pi) * atan2 y x) ++ \"\\nrender.filename = \\\"el-$p\\\"\")"
  ) |
  tee el-$p.f3.toml
  fraktaler-3-3~pre -P -b el.f3.toml el-$p.f3.toml
done
ffmpeg -r 3 -i el-%d.png el.gif

Common F3 TOML for rendering setup (file el.f3.toml):

bailout.iterations = 100100
bailout.maximum_reference_iterations = 100100
bailout.maximum_perturb_iterations = 4096
bailout.maximum_bla_steps = 4096
image.width = 640
image.height = 360
image.subframes = 16
render.save_png = true

[colour]
uniforms = []
shader = """
vec3 colour(void)
{
  const float gamma = 1.0;
  vec2 DE = getDE();
  float val = tanh(clamp(length(DE), 0.0, 4.0));
  return vec3(pow(val, 1.0 / gamma));
}
\
"""
