Had another look through the collection and implemented a variant on Exploitation Quantitative et Qualitative do Programme. I made the probabilites for the different cell shapes vary down the image, to get a vague leftwards pointing v shape.

import Diagrams.Prelude
import Diagrams.Backend.SVG.CmdLine (defaultMain)

import Data.Array (array, assocs, range)
import System.Random (StdGen, newStdGen, randoms)

main = newStdGen >>= defaultMain . diagram

diagram
  = bg white . fc black . lwO 0
  . flatten . grid . (randoms :: StdGen -> [Double])

flatten a = mconcat
  [ c # centerXY # translate (r2 (fromIntegral i, fromIntegral j))
  | ((i, j), c) <- assocs a
  ]

grid rs = array bs [ (ix, cell r ix) | (ix, r) <- range bs `zip` rs ]
  where bs = ((0, 0), (sizeW, sizeH))

cell r = choose r . cells

choose r = snd . head . dropWhile ((< r) . fst) . cummulative

cummulative weighted =
  let (weights, objects) = unzip weighted
      weights' = scanl1 (+) weights
  in  map (/ last weights') weights' `zip` objects

cells (i, j) =
  [ (ascending , tri 0)
  , (descending, tri 1)
  , (ascending , tri 2)
  , (descending, tri 3)
  , (ascending , cir id 0)
  , (descending, cir id 1)
  , (ascending , cir id 2)
  , (descending, cir id 3)
  , (ascending , cir negate 0)
  , (descending, cir negate 1)
  , (ascending , cir negate 2)
  , (descending, cir negate 3)
  ]
  where
    ascending  = (fromIntegral j / fromIntegral sizeH) ^ 2
    descending = (fromIntegral (sizeH - j) / fromIntegral sizeH) ^ 2
    corners k = take 3 . drop k . cycle $
      [ p2 (0, 0), p2 (1, 0), p2 (1, 1), p2 (0, 1) ]
    tri = strokeLoop . closeLine . fromVertices . corners
    cir f k = case corners k of
      [a,b,c] -> strokeLoop . closeLine $
        arcBetween a c (f (1 - sqrt 0.5)) <> c ~~ b

sizeW, sizeH :: Int
sizeW = 32 - 1
sizeH = 18 - 1

Download this Haskell source.
